Product Summary

The MAX1921EUT15+T step-down converter delivers over 400mA to outputs as low as 1.25V. The MAX1921EUT15+T uses a unique proprietary current-limited control scheme that achieves over 90% efficiency. The MAX1921EUT15+T maintains extremely low quiescent supply current (50μA), and its high 1.2MHz (max) operating frequency permits small, low-cost external components. This combination makes the MAX1921 an excellent high-efficiency alternative to linear regulators in space-constrained applications.

Parametrics

MAX1921EUT15+T absolute maximum ratings: (1)IN, FB, SHDN to AGND: -0.3V to +6V; (2)OUT to AGND, LX to PGND: -0.3V to (IN + 0.3V); (3)AGND to PGND: -0.3V to +0.3V; (4)OUT Short Circuit to GND: 10s; (5)Operating Temperature Range: -40°C to +85°C; (6)Junction Temperature: +150°C; (7)Storage Temperature: -65°C to +150°C; (8)Lead Temperature (soldering 10s): +300°C; (9)Continuous Power Dissipation (TA = +70°C)6-Pin SOT23: 696mW.

Features

MAX1921EUT15+T features: (1)Low-Voltage, 400mA Step-Down DC-DC Converters in SOT23; (2)Package Type: 6-Lead SOT23; (3)Dimensions: 60 x 41 mils.

Diagrams

MAX1921EUT15+T pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MAX1921EUT15+T
MAX1921EUT15+T
Maxim Integrated Products
DC/DC Switching Converters 400mA Step-Down DC/DC Converter
Data Sheet
0-2020: $0.89
2020-2500: $0.89
